PET Films & Sheets

Product Description

PETG film is Known as GPET,is a non-crystalline copolyester, pos-sesses CHDM, It is conposed of TPA, EG and CHDM by conden-sation polymerization. While, CHDM of PETG is the reason that its performance is differ from PET.PETG has no crystallization tem-perature,can easily be molding and bonding without albinism which is the major defect of PET material.

Product Specifications

Particulars	Values
Item	PETG Sheet Film
Width	Roll: 110-1280mm Sheet: 915*1220mm/1000*2000mm
Thickness	0.15-7mm
Density	1.33-1.35g/cm^3

Product Features

• Excellent clarity: : PETG sheet has excellent transparency similar to glass, allowing packaging products or printed graphics to be seen.
• Outstanding thermoforming performance: PETG sheets are easy to produce products with complex shapes and large stretch ratios. Moreover, unlike PC board and impact-modified acrylic, this board does not need to be pre-dried before thermoforming. Compared with PC board or acrylic, its molding cycle is short, the temperature is low, and the yield is higher.
• Toughness : The extruded sheet of PETG sheet is usually 15 to 20 times tougher than general acrylic and 5 to 10 times tougher than impact modified acrylic. PETG sheet has sufficient bearing capacity during processing, transportation and use, which helps prevent cracking.
• Weather resistance: : PETG sheet provides excellent weather resistance. It can maintain the toughness of the product and prevent yellowing. It contains ultraviolet absorbers, which can be co-extruded into a protective layer to protect the board from the harmful effects of ultraviolet rays.
• Easy to process : PETG sheet can be sawed, die-cut, drilled, punched, sheared, riveted, milled and cold-formed without breaking. Slight scratches on the surface can be eliminated with a hot air gun. Solvent bonding is also a normal operation. It is easier to process than general acrylic, impact modified acrylic or PC board, and can be processed for flocking, electroplating, static electricity and other processing.
• Excellent chemical resistance: PETG sheet can withstand a variety of chemicals and commonly used cleaning agents.
• Excellent chemical resistance: PETG sheet can withstand a variety of chemicals and commonly used cleaning agents.
• Eco-friendly and safety: The PETG sheet substrates are all environmentally friendly materials, which meet the requirements of food contact management.
• Economy: It is cheaper than a polycarbonate board, and it is more durable than polycarbonate board.

Product Application

• By using conventional molding methods, we can make PETG sheet from 0.15MM to 7MM, with outstanding toughness and high impact resistance, its impact resistance is 3~10 times that of modified polyacrylates, excellent molding performance, cold Bending is not white, no cracks, easy to print and decorate, widely used in indoor and outdoor signs, storage racks, vending machine panels, furniture, construction and mechanical baffles, etc.
• PCTG card is mainly used in Europe, but it has also been more and more used in North America and Asia. The reason is that it has a wide processing range, high mechanical strength and excellent flexibility. Compared with PVC, it has high transparency, good gloss, easy printing and environmental protection advantages.
• PETG materials are used in credit cards. Visa is one of the largest credit card companies in the world, with 580 million cards issued worldwide in 1998. The company has recognized glycol-based modified polyester (PETG) as its credit card material. For countries that require card materials to be more environmentally friendly, PETG can replace polyoxyethylene materials. Visa also pointed out: The results from 3 different experimental plants show that PETG meets all the requirements of the international credit card standard (150/IEC7810), so PETG cards may be widely used here.
